Complies with ASTM D6648, AASHTO T313 & TP87, EN 14771

Features

• Touchscreen controller with easy to use, step-through instructions
• Leveling legs
• Stainless steel, corrosion resistant construction
• 500 gram load cell with mechanical overload protection
• 0.25 in. Linear Variable Displacement Transducer (LVDT)
• NIST traceable platinum RTD
• Temperature Range: -40 - 25 ˚C
• Operating Temperature: Ambient to -40 ˚C
• Mechanical refrigeration system
• Cooling coil located in test bath. No pumping required.
• Programmable Test Parameters, Detailed Test Reporting
• Digital controls
• Out of tolerance indicator lights for: air bearing, LVDT, load cell, RTD, load shaft alignment & system check
•  USB port on front and back of unit for upgrades and data downloads, as well as printer connection
• Ethernet capabilities
• Latest BBR software
• VNC Viewer- Remote monitoring capabilities with smart phone or tablet app

Unit Includes

• Calibration Kit
• (1) Step disk & Index, (4) 50 gram weights, (2) 2 gram weights
• Confidence Beam, Non-Compliance Beam
• Wood Storage Case
• Specimen Mold Kit for (5) Molds (also sold separately - See OV-9510)
• Aluminum Casing Bars, Mylar Strips, & Holding Bands
• 127 mm Length, with end piece location marks
• 6.4 mm Thick, 12.7 mm Wide
• Crack Sealant Mold Kit for (6) Molds
• Holding bands
• Aluminum bars, end pieces & plate:
• (12) 165.00 mm x 19.00 mm Side Bar
• (12) 12.70 mm x 19.00 mm Spacer Bar
• (6) 177.00 mm 13.00 mm Bottom Plate
• Stylus & Clip

NOTES

• A source of compressed air with a pressure of at least 60 psi is required for operation
• Non-flammable Ethylene Glycol mixture recommended for cooling bath fluid

Electrical Requirements 115V, 1ph, 50/60 Hz

Dimensions: 24 in. W x 23.5 in. H x 26.5 in. D

Weight: Approximately 148 lbs.

• OV-9400 (115 volt)
• OV-9450 (230 volt)
